威德福Weatherford MG-1500 螺桿泵電驅動頭
MG-1500 Electric Direct Drive Provides a reliable, economic solution for a variety of PCP applications,
including heavy to light oil, coalbed methane, and water source wells
Applications
• PCP applications driven by electric or hydraulic motors Features and Benefits
• The small footprint is especially useful for height-restricted areas and aesthetically sensitive environments.
• Standard features include a hinged guard for easy sheave and belt inspection or replacement and a three-point lifting system for ease ofhandling.
• The centrifugal braking system provides a resistive torque that is proportional to speed, for a safe release of the backspin energy. Thebrake shoes automatically engage and retract based on speed, which results in a quick, complete, and controlled fluid dump, enabling production to resume quickly.
• The braking system is enclosed and immersed in synthetic oil to manage a wide range in operating temperatures and to lubricate all moving parts for a long service life.
Tool Description
The Weatherford MG-1500 drive is an electric, belt-driven drive with a torque capacity of 1,500 lbf-ft. It is compatible with Weatherford stuffing boxes and various wellhead connections.
