 High static torques • Maximum torque and power densities • Maximum dynamic response even with very short repetitive cycles

詳細(xì)資料
The DT high torque motor series provides an innovative concept for highly dynamic applications. With a high pole count and optimized lamination geometry, these motors achieve an excellent power density and a system-efficient torque. With this motor series you receive a compact drive that is particularly well-suited for applications with a high cycle frequency. The motors are available in convection-cooled and liquid-cooled versions.

Developed with high reliability, high dynamic response, compact dimensions, and largely maintenance-free operation in mind, this series with its high overload capacity is ideal for peak loads.

Applications
Positioning and actuating drives for drive tasks with exacting requirements for dynamic    response and power density
Variable-speed drive for continuous running
For applications with demanding cooling situations due to high integration density,   contamination or ambient temperatures
Connecting cable:
Copper conductor nominal cross-section
DT 5-20 = 2.5 mm2   DT 5-30 = 4mm2
Power connector size 1
